Complete a wide variety of framing jobs with the DEWALT 20V MAX* Brushless Cordless 30º Paper Collated Framing Nailer Kit. Designed to help minimize downtime between shots with an innovative flywheel that stays active for 6 seconds after the trigger is released, this lightweight cordless nailer removes the need for hoses and compressors. Install up to 530 sqft of sublooring per charge** and complete up to 100 ft. of wall framing per charge† with this next-generation tool that delivers powerful performance in a wide range of applications.
Applications
Residential Framing
Sheathing
Sublflooring
Setting Trusses
Punchout
Deck Building
Specifications
Battery Capacity [Ah]
5
Magazine Angle [deg]
30 Degree Paper Tape
Nail Diameter [in]
0.113-0.131
Nail Length [in]
2-3.5
Power Source
Battery
Product Height [in]
13.2
Product Height [mm]
335
Product Length [in]
13.9
Product Length [mm]
353
Product Weight [g]
3920
Product Weight [Kg]
3.92
Product Weight [oz]
138.4
Product Width [in]
5.6
Product Width [mm]
142
Additional Features
Cordless Convenience - Pneumatic framing pros can save up to 20 min. daily in setup and clean-up time by switching from a pneumatic nailer to a DEWALT® cordless framing nailer***.
Help Maximize Productivity - Install up to 530 sq. ft. of subflooring per charge** and complete up to 100 ft. of wall framing per charge†.
Powerful Performance - Finish a wide-range of applications with an powerful brushless motor.
Up To 72% More Sub-Flush†† - Drive nails up to 72% more sub-flush than previous generation††.
High-Strength Magnesium Magazine - High- strength magnesium magazine for durability.
Lightweight Design - Lighten your load on tough jobs with this tool that weighs only 8.65 lbs. (tool only).
Innovative Nose Design - Align, grip, and drive nails at aggressive angles with the redesigned nose specifically built for “Toe-Nailing” applications.
Help Minimize Downtime - Help minimize time between shots with Active Flywheel Technology in rapid sequential mode eliminating ramp-up time between shots.
Quick Setup - Show-up and get right to work with this cordless nailer requiring no compressors or hoses.
Simplify Inventory Management - Track and manage this Chip-Ready™ tool in the TOOL CONNECT™ system (Chip sold separately).
Nail Capacity - Take on tough jobs with up to a 3-1/2 in. nail capacity.
On-Site Serviceability - Limit maintenance delays with field serviceable springs and driver blade.
Compatible With Extended Magazine (DZN920) - Hold 2 strips of nails using an optional extended magazine (DZN920) constructed from high-grade magnesium (magazine sold separately).
Includes
(1) Nailer
(1) DCB205 Battery
(1) DCB1104 Charger
(1) Belt Hook and Screw
(1) No Mar Tip
(1) Manual
(1) Hex Wrench
(1) Soft Bag
Warranty Information
3 Year Limited Warranty, 1 Year Free Service, 90 Days Satisfaction Guaranteed
We’re confident of the quality of our products, and we’ll repair, without charge, any defects due to faulty materials or workmanship within the specified warranty.
